Inline Sensor Housing
Thread Connection
Key Features: Type FIL
• Highly resistant
to aggressive chemicals suited for wastewater treatment-chemical processing-metal finishing
• Mechanical
thread design for direct connection into the existing flow stream holding sensor securely in place
• Suitable for 12mm and PG 13.5 electrodes with protective sleeve to protect sensors from physical damage
• Stable environment around sensor tip reducing noise in the readings caused by high-velocity or erratic flow
• Manufactured for 16 bar High pressurised process applications - Temperature: 60°C Max
Applications
| Swimming Pools | Wastewater | Drinking Water | Cooling Towers | Irrigation
|
Inline pH Senor Holder
Union Seal Mechanism
Key Features: Type SPP
• Highly
resistant to aggressive chemicals suited for wastewater treatment-chemical processing-metal finishing
• The simple union type mechanism provides an impermeable leak-free seal holding electrodes firmly in place
• Suitable for 12mm and PG 13.5 electrodes with protective sleeve to protect sensors from physical damage
• Stable environment around sensor tip reducing noise in the readings caused by high-velocity or erratic flow
• Manufactured for 16 bar High pressurised process applications - Temperature: 60°C Max
Applications
| Swimming Pools | Wastewater | Drinking Water | Cooling Towers | Irrigation
|
Inline Electrode Housing
Twist-Lock Mechanism
Key Features: Type PSS-3
• Robust cost
effective durable design for simple installation into pipework with excellent chemical resistance
• The simple twist-lock mechanism provides an impermeable leak-free seal holding electrodes firmly in place
• Suitable for 12mm & PG 13.5 electrodes and sensors that can be inserted to the required pipework
depth
• Manufactured for 12 bar High pressurised process applications - Temperature: 60°C
Max
Applications
| Swimming Pools | Wastewater | Drinking Water | Cooling
Towers | Irrigation |
Inline Electrode Housing
Twist-Lock Mechanism
Key Features: Type PSS-3S
• Superior chemical
resistance material doesn't' degrade with good thermal stability against higher temperatures
• The
simple twist-lock mechanism provides an impermeable leak-free seal holding the electrode firmly in place
• Suitable for standard 12mm diameter electrodes and sensors allows adjustment to the required process depth
• Manufactured for 7 bar medium pressure process applications - Temperature: 60°C Max
Applications
| Swimming Pools | Wastewater | Drinking Water | Cooling Towers | Irrigation
|
Accommodates
One Probe For:
One Probe For:
Accommodates
One Probe For:
One Probe For:
Accommodates
One Probe For:
One Probe For:
Electronic Dosing Systems
Tel 01299 825 656 Email info@electronicdosingsystems.co.uk
Solutions For All Metering & Measurement Processes
Copyright: - Electronic Dosing Systems 2026
| Water Treatment | Electroplating | Cooling Towers | Industrial Boilers | Paper Industry | Vehicle Washing |
Wastewater | Swimming Pools & Spas |
| Beverage & Brewery | Petroleum | Bottle Washing | Hygiene &
Cleaning | Biotechnology | Food Industry | Pharmaceutical Industry |
Simple Measurement Solutions:
In industrial water treatment how you install your electrodes is just as important as the
sensors themselves our range of iinline probe holders provide a practical and cost effective solution for seamless
integration directly into the existing main pipework without interrupting the process flow, engineered to
house 12mm diameter pH, Redox and Conductivity electrodes inline holders ensures the liquid remains in contact with
the sensor to maintain a stable measurements even when installed in processes with hash environment conditions.
Pressure & Temperature Resilience:
Designed for medium and high pressurised systems holder use a twist lock mechanism
that provides an impermeable seal with the housing acting as an additional protective shroud around the electrode
from buildup or "dead zones" or sediment around the sensor's tip that could directly impact measurement accuracy, engineered
from PVC and Polypropylene materials they are highly resistant to most acids, alkalis and organic solvents whilst offering reasonable operating
temperature limits compatible with most electrodes used in water treatment systems.
Simplified Maintenance Schedules:
Inline probe holders offer significant advantages in both measurement accuracy and operational
efficiency their simple design minimises downtime when performing scheduled maintenance such as cleaning, calibration
or replacing the electrode achieved within minutes with minimal impact to the working process.
Inline pH Electrode Holder
Polypropylene (PP) inline pH/Redox (ORP) electrode holder highly resistant to a broad
range of corrosive substances including acids, alkalis, salts and organic solvents designed to be mounted into the
main flow stream or bypass manifold loop with a standard 12mm sensor fixed in place using a
twist-lock mechanism providing a impermeable leak-free seal suitable for medium pressure systems, allows
sensor to be inserted to the correct depth in larger diameter pipework without compromising measurement accuracy.
Inline Redox Electrode Housing
Robust PVC inline pH or redox (ORP) electrode housing for high pressure processes with
excellent chemical resistance designed to be mounted into the pipe stream or bypass loop in industrial
water treatment applications housing a standard 12mm or PG 13.5 type sensors securely fixed in place through
a twist-lock mechanism providing a impermeable leak free seal, sensors can be inserted to the required depth ensuring
continuous real-time measurements without compromising the integrity of the electrode.
Inline pH Sensor Holder
Polypropylene inline pH/Redox (ORP) sensor holder for high pressure processes with
union connection designed to be mounted into the existing pipe stream or bypass manifold loop configuration housing
either a standard 12mm or PG 13.5 type sensors with impermeable seal connection, specifically suited
for industrial demanding and harsh environments where chemical resistance and physical durability are critical without compromising
the structural integrity including measurement accuracy of the electrode.
Accommodates
One Probe For:
One Probe For:
Inline Redox Sensor Housing
Polypropylene inline pH/Redox (ORP) sensor housing for high pressure processes with
union connection designed to be mounted into the existing pipe stream or bypass manifold loop configuration housing
either a standard 12mm or PG 13.5 type sensors with impermeable seal connection, specifically suited
for industrial demanding and harsh environments where chemical resistance and physical durability are critical without compromising
the structural integrity including measurement accuracy of the electrode.
