PVC Dosing Tubing
Transparent pvc tubing good chemical resistance designed for low pressure applications due to
it's excellent flexibility and capacity to retain it's operational structure properties thereby providing an extended
service life and reduced routine replacement requirements due to it smooth internal wall, extremely versatile durable
tubing with glass clear transparency for visual inspection utilised in the chemical, food and beverage
sectors as it doesn't impart taste or odour into the process contents.
Chemical Tubing
Dosing Hose
PVC Clear Hose
PVC (PolyVinyl Chloride) food grade tubing fully transparent for clear visibility fair working
temperature and good flexibility properties for ease of use suitable for a wide range and diverse low pressure
applications in the food and beverage industries, light weight hose utilised on suction side of chemical dosing pumps
including peristaltic low pressure dosing systems.
Technical Details
» Excellent flexibility and good chemical
resistance
» Doesn't impart taste or odour into contents.
» Lower pressure chemical applications
» Working temperature
-15°C ÷ 60°C
» Supplied in 30m to 300m continual lengths
Compliant to ISO 9001-2015 - EU
10/2011 Standard
N.B. Double wall tubing significantly increases chemical containment protection throughout the installation
Copyright: - Electronic Dosing Systems 2025
| Water Treatment | Electroplating | Cooling Towers | Industrial Boilers | Beverage & Breweries | Vehicle
Washing | Waste Water Treatment | Swimming Pools & Spas |
| Paper Industry | Petroleum | Bottle Washing |
Hygiene & Cleaning | Biotechnology | Food Industry | Pharmaceutical Industry |
Electronic Dosing Systems
Tel 01299 825 656 Email info@electronicdosingsystems.co.uk
Solutions For All Metering & Measurement Processes
PVC Reinforced Dosing Tubing
PCV reinforced tubing good chemical resistance with polyester fibre layer significantly
increases mechanical strength for high pressure applications excellent flexibility and capacity to retain it's
operational structure properties extending the hose service life, extremely durable tubing with good transparency utilised in the
food and beverage industry as it doesn't impart taste or odour into contents often connected to mechanical
dosing pumps or used as chemical containment protection with other dosing tubing.
PVC Reinforced Hose
PVC braided food grade reinforced tubing with polyester fibre between pvc layers
that significantly improves mechanical strength whilst retaining good transparency reasonable working temperature and UV
protection, suitable for high pressure applications often used in the food and beverage sectors often used
to transfer aggressive chemicals through mechanical dosing pumps.
Technical Details
» Excellent flexibility
and good chemical resistance
» Doesn't impart any taste or odour into contents.
» High pressure (20 bar) chemical applications
» Working temperature
-15°C ÷ 60°C
» Supplied in 30m to 100m continual lengths
Compliant to ISO 9001-2015 - EU
10/2011 Standard
N.B. Double wall tubing significantly increases chemical containment protection throughout the installation
Polyethylene Dosing Tubing
Polythene tubing food grade compliant excellent durable chemical resistance
properties and increased mechanical strength and flexibility for high pressure applications with capacity
to retain it's original operational structure properties extending the tubing service life, extremely
durable tubing with good transparency utilised in the food and beverage sector as it doesn't impart
taste or odour into contents often used to transfer chemicals and reagents through chemical dosing pumps.
Polyethylene Hose
Polyethylene dosing tubing with good transparency and flexibility provides reasonable UV protection with excellent
mechanical strength properties suitable for high pressure applications, often used with-in the food, beverage and chemical industry's
due to it's resilience against most water treatment chemicals and reagents utilised to transfer liquids from chemical dosing
pumps.
Technical Details
» Excellent flexibility and good chemical resistance
» Doesn't impart
any taste or odour into contents
» Burst pressure (50 bar) chemical applications
» Working temperature
-15°C ÷ 60°C
» Supplied in 30m to 100m continual lengths
Compliant to ISO 9001-2015 - EU
10/2011 Standard
N.B. Double wall tubing significantly increases chemical containment protection throughout the installation
PTFE Dosing Tubing
PTFE (PolyTetraFluoroEthylene) hose manufactured using premium raw materials has
perfectly smooth extremely low co-efficient of friction surfaces resistant to virtually most solvents and chemicals benefiting
from high degree of UV protection including an extremely wide operating temperature range, ptfe tubing
is non-flammable electrically insulated retains it's original structure even at high pressures suited to all manner of applications
often used to transfer chemicals and reagents through chemical dosing pumps.
PTFE Hose
PTFE dosing tubing with good transparency and flexibility provides high degree of resistance against most
aggressive chemicals with excellent mechanical strength properties suitable for high pressure applications, has remarkable
anti-stick properties ensuring dosing line remains efficient with minimal service down time due to it's resilience against
most chemicals and solvents.
Technical Detail
» Excellent flexibility and exceptional chemical
resistance
» Extremely low co-efficient of friction surfaces
» Burst pressure (40 bar) @ 20°C Temp
» Working temperature
-270°C ÷ 250°C
» Supplied in 30m to 100m continual lengths
Compliant to ISO 9001-2015 - EU 2015
863 Standard
N.B. Double wall tubing significantly increases chemical containment protection throughout the installation
PVDF Dosing Tubing
PTFE (PolyVinyliDeneFluoride) hose manufactured with premium materials benefiting
with inherent high purity smooth internal surfaces and very low fluid permeation through it's wall being widely employed
in pure water systems and delivery ultra-pure fluids in the pharmaceutical industry, highly resistant
to most aggressive and concentrated chemicals with a wide operating temperature range offering full UV
protection making it an excellent tubing option when dosing the chemical sodium hypochlorite.
PVDF Hose
PVDF dosing tubing provides high degree of resistance against aggressive and concentrated chemicals with
full UV protection and higher mechanical strength properties particularly elevated pressure dosing applications,
the material of choice in high purity and critical fluid handling environments often utilised in food
processing applications and when dosing sodium hypochlorite.
Technical Detail
» Excellent flexibility
and exceptional chemical resistance
» Resistant to abrasion offering full UV protection
» Burst pressure
(110 bar) @ 20°C Temp
» Working temperature -40°C ÷ 140°C
» Supplied in 30m to 100m continual lengths
Compliant
to ISO 9001-2015 - EU 2015 863 Standard
N.B. Double wall tubing significantly increases chemical containment
protection throughout the installation
